Diamond End Mills for Non-Ferrous Materials - PCD Diamond - Corner Radius

Material Specific End Mills
Diamond End Mills for Non-Ferrous Materials - PCD Diamond - Corner Radius

Material Specific End Mills

The PCD diamond brazed onto the solid carbide body of this corner radius end mill increases tool life when machining aluminum, copper, brass, bronze, plastics, graphite, carbon, carbon fiber materials, green carbide, gold, silver, magnesium, zinc, and green ceramics.

  • PCD Diamond brazed on carbide body
  • Center cutting
  • Recommended work piece material: Aluminum, Copper, Brass, Bronze, Plastics, Graphite, Carbon, Carbon Fiber Materials, Green Carbide, Gold, Silver, Magnesium, Zinc and Green Ceramics.

Advanced Search

CUTTER DIAMETER LENGTH
OF CUT		 OVERALL REACH CORNER RADIUS FLUTES SHANK DIAMETER OVERALL LENGTH PCD DIAMOND COATED Add to Cart Default Sort
D1
+.000"-.002"
 L2
+.020"-.000"
 L3
+.020"-.000"
 R
+.001"-.001"
 # D2 L1 TOOL # PRICE
3/32 3/16 3/8 .010 1 1/8 1-1/2 12206 $305.70 00000001
1/8 1/4 1/2 .015 1 1/8 1-1/2 12208 $305.70 00000002
3/16 1/4 5/8 .015 2 3/16 2 12212 $327.30 00000003
1/4 1/4 3/4 .010 2 1/4 2-1/2 858916 $343.40 00000004
1/4 1/4 3/4 .030 2 1/4 2-1/2 12216 $343.40 00000005
1/4 1/4 3/4 .060 2 1/4 2-1/2 847316 $343.40 00000006
3/8 1/4 15/16 .030 2 3/8 2-1/2 12224 $424.30 00000007
1/2 1/4 1 .030 2 1/2 3 12232 $492.00 00000008
